Geometry
Top Tube Length: 20.75"
Rear End Length: 12.6"
Head Tube Angle: 75.5°
Seat Tube Angle: 71°
BB Height: 11.8"
Standover: 8.8"
Frame: Chromoly top, down and head tube, Double Gussets
Fork: Chromoly Steerer Tube, 25 mm Offset , Tapered Legs
Bar: 4-piece, 9" rise, 29" width, 12° back sweep, 3° up sweep
Stem: FIT Forged Top Load, 50 mm reach
Headset: Integrated, sealed bearings
Grips: FIT Crossfit
Brake Mounts: thread-on
Rear Brake: U-Brake
Brake Lever: 2-finger
Brake Cable: Linear
Gearing: 25/9 RHD
Cranks: Tubular Chromoly, 165 mm length, RHD
Bottom Bracket: Mid, sealed bearing
Sprocket: Fit Key 25T
Pedals: Fit PC
Chain: KMC S1
Front Hub: sealed bearings, 10 mm axle, 17 mm nuts
Rear Hub: Freecoaster, sealed bearings, 14 mm axle, RHD, 17 mm nuts
Front Rim: FIT S1W, 36H, single wall, alloy
Rear Rim: FIT OEM Double Wall, 36H, alloy
Tires: FIT F/U 20" x 2.4"
Seat: Seat Combo
Seat Clamp: integrated
Pegs: 4x 100 mm steel pegs
Weight: 12.85 kg
